- Powered by NVIDIA® Jetson Orin™ NX up to 100 / 70 TOPS
- Business Card Size (90mmx55mm)
- 3xM.2, 8xMIPI CSI-2 Lanes and RS232 / RS485 / GPIO
- 2xUSB3.2 Gen2
- 1xMini DisplayPort
| CPU | NVIDIA Jetson Orin NX 8GB 6-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU 1.5MB L2 + 4MB L3 |
|---|---|
| NVIDIA Jetson Orin NX 16GB 8-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU 2MB L2 + 4MB L3 |
|
| GPU | 1024-Core NVIDIA Ampere Architecture GPU with 32 Tensor Cores |
| API Performance | NVIDIA Jetson Orin™ NX 8GB, 70 TOPS |
| NVIDIA Jetson Orin™ NX 16GB, 100 TOPS | |
| System Memory | NVIDIA Jetson Orin™ NX 8GB, 8GB LPDDR5 |
| NVIDIA Jetson Orin™ NX 16GB, 16GB LPDDR5 |
| Storage | Supports External NVMe 1xMicro SD Card Slot |
|---|---|
| Display Interface | 1xMini DP1.4 |
| Ethernet | 1xRJ45 for 10/100/1000Mbps Ethernet DHCP Client |
| Expansion Slot | M2 1xM.2 2230 M Key PCIe Gen4x2 Slot 1xM.2 2230 M Key PCIe Gen4x1 Slot 1xM.2 2230 E Key PCIe Gen4x1 Slot |
| USB | 1xUSB3.2 Gen2 ( Type-A ) 1xUSB3.2 Gen2 (Type-C) |
| MIPI | 8xMIPI CSI-2 Lanes (D-PHY 2.1, 2x4 MIPI Lanes, Support MIPI Camera, Capture Card) |
| Perherial Communication | 14 Pin Header 1xUSB2.0 4xGPIO 1xUART 1xI2C 8 Pin Phoenix Connector ( CON1 ) 1xGPIO 2xI2C 8 Pin Phoenix Connector ( CON6 ) 1xGPIO 1xRS232 1xRS485 |
| Misc. Features | Firmware Upgradable |
