- Powered by NVIDIA® Jetson Orin™ NX up to 100 / 70 TOPS
- Business Card Size (90mmx55mm)
- 4xGMSL2 In
- 1xCAN Bus
- 1xUSB3.2 Gen2
- 1xMini DisplayPort
| CPU | Jetson Orin NX 8GB 6-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU 1.5MB L2 + 4MB L3 |
|---|---|
| Jetson Orin NX 16GB 8-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU 2MB L2 + 4MB L3 |
|
| GPU | 1024-Core NVIDIA Ampere Architecture GPU with 32 Tensor Cores |
| API Performance | NVIDIA Jetson Orin™ NX 8GB, 70 TOPS |
| NVIDIA Jetson Orin™ NX 16GB, 100 TOPS | |
| System Memory | NVIDIA Jetson Orin™ NX 8GB, 8GB LPDDR5 |
| NVIDIA Jetson Orin™ NX 16GB, 16GB LPDDR5 |
| Storage | Supports External NVMe 1xMicro SD Card Slot |
|---|---|
| Display Interface | 1xMini DP1.4 |
| Ethernet | 1xRJ45 for 10/100/1000Mbps Ethernet DHCP Client |
| Expansion Slot | M2 1xM.2 2230 M Key PCIe Gen4x2 Slot 1xM.2 2230 E Key PCIe Gen4x1 Slot |
| USB | 1xUSB3.2 Gen2 (Type-C) |
| Perherial Communication | Jumper 1 1xI2C Jumper 2 1xUART 1xCAN Bus |
| Misc. Features | Firmware Upgradable |
| Video Input | 4xGMSL2 |
|---|
