| CPU / Chipset | Intel® Apollo Lake SoC Processor J3455, 1.50 GHz, 10W/ SoC |
|---|---|
| Graphic | Intel® integrated HD 500 Graphics |
| RAM | Single channel support 1867MHz DDR3L SODIMM socket, up to 8GB |
| OS Support | Windows 10 IoT Enterprise LTSC |
| Storage | M.2 Type SATA III SSD 2280 slot interface x 1 2.5" drive bay support SATA3 HDD/SSD |
| Expansion | 1 x M.2 (E key, 2230), 1 x PCIe (x1), 1 x Mini-PCIe 52 pin card-edge type |
| Display Size | 15.6" LCD |
| Display | 1366x768 (HD), 16.7M colors, 170(H) / 160(V), 400 nits (Typ. Center point), CR:500 : 1 (Typ) Customized 1920 x 1080 (FHD), 16.7M colors, 160 (H) /140(V), 400 nits (Typ. Center point), CR: 700:1 (Typ.) |
| Touch Screen | Projected Capacitive Multi-Touch Panel / Light Transmission: ≧84% / Hardness: 7H pencil, pressure 765g/45° / Life: 50000 |
| WMP-155 CP0A (STD) | WMP-155 CP0B (ISO) | |
|---|---|---|
| USB | 2 x USB3.0, 2 x USB2.0 | 2 x USB3.0, 2 x USB2.0, 1 x ISO USB2.0 |
| COM | 1 x RS232/422/485, 1 x RS232 | 1 x RS-232, 1 x RS232/RS422/RS485, 1 x ISO RS-232, 1 x ISO RS232/RS422/RS485 |
| LAN | 2 x RJ45 | 2 x RJ45, 1 x ISO LAN |
| Audio | 2 x 3.5mm phone jack connector (Line-out, Mic-In) / 2 x DP | |
| Control Hot Key (R to L) | Power Button // Mute // Audio adjustment+- // Brightness+- // LCD on/off // Clean me // Dis-webcam // Function key | |
| Cooling | Fanless |
|---|---|
| Power Adapter | AC input 100~264V / 47 ~ 63 Hz / DC output 12V, 100W |
| Temperature | Operating Temperature: 0~40°C (Burn-In not Airtight) / Storage Temperature: -20~60°C |
| Humidity | Operating & Storage:10 ~ 90%, non-condensing |
| IP Rating / Housing | Front Side IP65, IPx1 for whole system / Plastic White w/Anti-bacteria (MRSA) Housing |
| Dimensions (Net) | 430 mm (H) x 300 mm (V) x 83 mm (T) |
| Weights (Net) | 5.2 kg (w/o power adapter) |
| Mounting | Optional Stand, VESA 75/100 |
| Certification | EMC: FCC Part 18 Class B, VCCI Class B (PSU w/PSE) CE: EN60601 ~ 1-2: 2015(V4.0) MDD: EN60601-1: 2006/A1:2013(V3.1) CUL: CAN/CSA-C22.2 No.60601-1:2014(V3.1), ISO14971/ IEC62133 |
