| CPU | Supports 12/13th Gen. Intel® Core i9/i7/i5 Processor up to 65W |
|---|---|
| Chipset | Intel® R680E Chipset |
| GPU Card (Optional) | Based on NVFF5.0 112 x 269 x 39 mm (for Dual slots card) 112 x 244 x 19 mm (for Single Slot card) |
| Memory | 4x 288-pin, U-DIMM |
| Storage | 4x 2.5" SATAIII SSD 1 x M.2 M-Key Slot, Support PCIe Gen4 x4 for NVME/SATA, Size 2280 1 x M.2 M-Key Slot, Support PCIe Gen4 x4 for NVME, Size 2280 |
| USB | 8 x USB 3.2 Gen2 x 1 (Type-A) 1 x USB 3.2 Gen2 x 2 (Type-C) |
| LAN | 3 x 2.5G RJ-45 Ethernet (I226-LM, LAN2/LAN3 optional with 802.3at PSE up to 30W/ch) 1 x 10G BASE-T RJ-45 (Marvell AQC113) |
| Serial port | 1 x RS-485 (COM3, RJ45) 2 x RS-232/422/485 (COM1/2, DB9, Default RS-232) |
| Display | 1 x HDMI 2.0 2 x DP++ 1.4 (VGA optional / GPIO either one) |
| Expansion Slots | 1x M.2 E-Key 2230 (USB2.0/PCIe) 1x M.2 B-Key 3052(USB2.0/USB3.2) 1x PCIe Gen4 x16 or Gen4 x8 (PCIe x16 slot) 1x PCIe Gen4 x8 (PCIe x16 slot) 1x PCIe Gen3 x4 (PCIe x4 slot) 1x PCIe Gen3 x4 (PCIe x16 slot) 1x PCIe Gen3 x1 (PCIe x1 slot) |
| SIM Slot | 1x Nano SIM Slot |
| GPIO | 8 x bits GPIO |
| Audio | 1 x Line-out, 1 x Mic-in |
| Button | 1 x Power button 1 x AI button |
| Indicator | PCIe Slot-1&2 (POWER/FAN/TEMP) |
| MISC. Function | OOB (out of band), Built-in Innodisk – InnoAgent |
| Power Consumption | Full loading : up to 600 Watts |
| Power Input / Connector | DC-in 24~48V (Power input up to 600W) , 4-pin Terminal Block |
| Dimension (WxDxH) | 340 x 215 x 279 mm |
| Mounting | Wall mount / Desk mount |
| Net Weight | 11 kg |
| Vibration | 1Grms ,IEC60068-2-64,Random,5 ~ 500 Hz ,1Hr / Axis (operation, w/o PCIe Card) |
| Shock | 10G, IEC 60068-2-27, Half Sine, 11 ms Duration (operation, w/o PCIe Card) |
| Temperature | Operating Temp.: 0°C ~ +50°C (32°F ~ 122°F)(w/o GPU) Operating Temp.: 0°C ~ +50°C (32°F ~ 122°F)(w/ 165W Passive GPU) Operating Temp.: 0°C ~ +40°C (32°F ~ 104°F)(w/ 300W Active GPU) Storage Temp.: -40°C ~ +85°C (- 40°F ~ 185°F) |
| Humidity | 95% @ 40°C Related Humidity, Non-condensing |
| OS Support | Windows 10 IOT LTSC / Windows 11 / Ubuntu 20.04/22.04 |
| Security | TPM 2.0 |
| Certification | CE / FCC Class A / UKCA / LVD / RoHS |
