Nvidia Jeson AGX Orin AI BOX eNVP-JAO-AI-V0008

eNVP-JAO-AI-V0008

Nvidia Jetson AGX Orin AI BOX

Fanless AI edge embedded box PC
8-core NVIDIA Carmel Arm v8.2 64-bit CPU
1792 Nvidia CUDA cores and 56 Tensor Cores (Nvidia Ampere architecture)
Onboard 32 GB 256-bit LPDDR4x 136.5GB/s
Supports 1x 10GbE port
Supports 1x M.2 M key 2280 for NVMe SSD
Supports 1x M.2 B key 3042/3052 for 4G/5G module
Supports 1x M.2 E key 2230 for WiFi/BT module
Supports 2x SATA port, 1x SD Card
Supports 2x USB 3.0, 2x USB 2.0
Supports 2x CANBus, 3x UART, 1x RS-485, 2x I2C, 2x SPI, 8x GPIO, +5V, +3.3V (optional)
Supports 9V to 55V wide-range DC input

Processor	8-core Arm® Cortex® -A78AE v8.2 64-bit CPU
Main Memory	Onboard 32GB 256-bit LPDDR5
Audio Input	1x Audio In/Out
Audio Output	1x Audio In/Out
System Memory	1 x 10GbE port ; 1 x GbE port POE : 10/100 MbE x 8 /PoE (Single 25W, Total 75W)
WiFi / BT	Supported (via Expansion Slot)
4G / 5G	Supported (via Expansion Slot)
Power Supply	DC 9-55V (3-pin terminal block) ACC function
Dimensions (W x D x H)	242 x 177 x 94 mm (D x W x H)
Operating Temp.	-20°C ~ 60°C (according to IEC60068-2 with 0.5 m/s AirFlow)
Storage Temp.	-40°C ~ 85°C
Storage Humidity	10% ~ 90% (non-condensing)
Certification	CE/ FCC Class A, according to EN 55032 & EN 55035; Other certifications (By Project)
