- Powered by NVIDIA® Jetson Orin™ NX
- Onboard 16GB / 8GB 128-bit LPDDR5
- Multiple I/O interface connections for data collection Gigabit LAN, USB 3.1, Serial Port, CAN-FD
- Wide operating temperature range -20°C to 60°C
| Processor | 8/6-core Arm® Cortex®-A78AE v8.2 64-bit CPU |
|---|---|
| Memory | Onboard 16GB / 8GB 128-bit LPDDR5 |
| Ethernet | 2 x GbE LAN, RJ45 |
| Expansion Slot | 1 x SIM card slot, 1 x Micro SD slot |
| Power Supply | 9 to 36 VDC, Max. 25W (with Fan) |
| Dimensions (W x D x H) | 136mm x 110mm x 57mm |
| Gross Weight | 0.9 kg |
| Operating Temperature | -4°F ~ 122°F (-20°C ~ 50°C) |
| Storage Temperature | -40°F ~ 176°F (-40°C ~ 85°C) |
| Storage Humidity | 10% ~ 95% relative humidity, non-condensing |
| Certification | CE, FCC |
