- Powered by NVIDIA® Jetson Orin™ NX
- Multiple I/O interface connections for data collection
- Gigabit LAN , USB 3.2, Series Ports, HDMI
- Wide range power input 9~36VDC
- Compact, lightweight and conveniently portable AI BOX
| Processor | NVIDIA® Jetson Orin™ NX 6/8-core Arm® Cortex®-A78AE v8.2 64-bit CPU |
|---|---|
| Memory | Onboard 8/16GB 128-bit LPDDR5 |
| Ethernet | 1 x GbE LAN, RJ45 |
| WiFi / BT | 1 x M.2 E-Key 2230 |
| Power Supply | 9 to 36 VDC |
| Dimensions (W x D x H) | 94.6mm x 76mm x 28.55mm |
| Gross Weight | 0.3 kg |
| Operating Temperature | -4°F ~ 140°F (-20°C ~ 60°C) |
| Storage Temperature | -40°F ~ 176°F (-40°C ~ 85°C) |
| Storage Humidity | 10% ~ 95% relative humidity, non-condensing |
| Certification | CE, FCC |
